2017 Honda FOURTRAX RINCON

2017 Honda FOURTRAX RINCON
Black
MSRP: $9,399.00
Manufacturer: Honda
Condition: New

Description

The outdoors can be a rough place—hot, cold, wet, dry, rocky, muddy, steep. But the smart outdoorsman—or outdoorswoman—knows that you don’t have to suffer. They find a way to smooth it instead of roughing it. And the Honda Rincon is one of the most refined, smooth, comfortable ATVs to ever take on what mother nature has to offer. The Rincon stands at the top of our ATV lineup. It’s built around our biggest ATV engine, and it’s a class-leader when it comes to comfort, ride quality, and innovation too. As with any Honda, it all starts with the engine: a liquid-cooled 675cc single-cylinder featuring a twin-plug cylinder head. The longitudinal-crankshaft layout (a Honda innovation) means more power actually gets to the ground, so the Rincon can offer the real-world power of the competition’s bigger, heavier models. Premium long-travel suspension, rugged bodywork, strong steel racks front and rear—the Rincon’s list of features just keeps going on and on. One thing you can’t see but is readily apparent is the Rincon’s all-day comfort, something serious ATV riders will appreciate. And then there’s just the way the Rincon looks: Strong. Purposeful. Like a flagship ATV should. So forget about putting up with a rough rider. Treat yourself to a Honda Rincon, and discover just how comfortable “roughing it” can be. Important Safety Information: Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner’s manual thoroughly.

  • Independent Rear Suspension

    Independent Rear Suspension

    The Rincon's IRS returns two big benefits: First, it helps ensure constant tire contact with the ground for superior traction; second, it gives you an ultra-smooth ride over rough terrain, so you don't get beat up on the trail.

  • Lower Emissions, More Range

    Lower Emissions, More Range

    With its 675cc liquid-cooled, fuel-injected four-stroke engine, the Rincon can power through terrain and trails with ease. The twin-plug cylinder head and an oxygen sensor give the Rincon great fuel efficiency, too.

  • Three-Speed Automatic Transmission

    Three-Speed Automatic Transmission

    No belts to slip or clutches to wear out on the Rincon—it features an automotive-style three-speed automatic transmission just like a truck’s, so you can depend on it for both a smooth ride and years of trouble-free service.

Specifications

ENGINE

Engine Type
675cc liquid-cooled OHV semi-dry-sump longitudinally mounted single-cylinder four-stroke
Bore And Stroke
102mm x 82.6mm
Induction
Electronic fuel injection (PGM-FI), 40mm throttle bodies
Ignition
Full-transistorized type with electronic advance
Starter
Electric with auxiliary recoil


DRIVE TRAIN

Transmission
Automatic with hydraulic torque converter, three forward gears, Reverse, and electronic controls
Driveline
Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential


CHASSIS / SUSPENSION / BRAKES

Front Suspension
Independent double-wishbone; 6.9 inches travel
Rear Suspension
Independent double-wishbone; 8.0 inches travel
Front Brakes
Dual hydraulic 180mm disc
Rear Brakes
Single hydraulic disc
Front Tires
25 x 8-12
Rear Tires
25 x 10-12


DIMENSIONS

Length
83.2 inches
Width
46.8 inches
Height
47.5 inches
Wheelbase
50.8 inches
Seat Height
34.5 inches
Ground Clearance
9.1 inches
Curb Weight
657 pounds (Red - aluminum wheels); 669 pounds (Honda Phantom Camo®, Black - steel wheels)
Fuel Capacity
4.4 gallons, including 1.2-gallon reserve
Turning Radius
10.8 feet


OTHER

Model Id
TRX680FA
Emissions
Meets current California Air Resources Board (CARB) off-road emissions standards.
Available Colors
Red, Honda Phantom Camo®, Black
Note
No operator under age 16. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.


FACTORY WARRANTY INFORMATION

One Year
Transferable limited warranty; extended coverage available with a Honda Protection Plan.


All inventory listed is subject to availability and prior sale. Manufacturer's Suggested Retail Price (MSRP) if shown for a vehicle excludes set-up, freight, taxes, title, licensing or other dealer charges, and is subject to change. Individual prices may vary. Please request a quote for specific pricing.
