2016 Can-Am OUTLANDER XT 1000R

2016 Can-Am OUTLANDER XT 1000R
Brushed Aluminum
MSRP: $12,849.00
Manufacturer: Can-Am
Condition: New

Description

Expand your off-road capabilities with added features – and added value. Well equipped with Tri-Mode Dynamic Power Steering (DPS), a 3,000-lb winch, and heavy-duty front and rear bumpers.

  • CATEGORY-LEADING PERFORMANCE

    Available with the 48-hp Rotax 570, 62-hp Rotax 650, new 78-hp Rotax 850 or 89-hp Rotax 1000R liquid-cooled V-Twin engine, with four valves per cylinder and single overhead camshafts, the signature Can-Am engine lineup offers unmatched power for a true performance edge.

  • PRECISION-ENGINEERED HANDLING

    The Tri-Mode Dynamic Power Steering (DPS) offers three levels of rider-adjustable steering assistance that can be adapted to match the terrain while also reducing kickback to the steering.The amount of assistance varies with the vehicle's speed to adjust the steering input effort to a comfortable level.

  • SMOOTH RIDE

    12-in cast-aluminum wheels with machined finish. The centerless design reduces unsprung weight and offers improved strength. The 26-in, 3-ply Carlisle ACT tires feature a tread pattern that is aggressive enough to tackle tough terrain, yet provide a smooth ride.

  • POWERFUL WINCH

    This powerful winch with a 3,000-lb (1,361 kg) capacity is factory-installed and can handle the toughest situations.

  • ADDED PROTECTION

    The front and rear bumpers are factory installed and are covered by a factory warranty. The added protection gives peace of mind in rugged conditions.

Specifications

ENGINE

ENGINE
1000R
TYPE
89 hp, Rotax 976 cc V-twin, liquid cooled
FUEL DELIVERY SYSTEM
Electronic Fuel Injection (EFI)
TRANSMISSION
CVT, P / R / N / H / L, standard engine braking
DRIVE TRAIN
Selectable 2WD / 4WD with Visco-Lok— QE auto-locking front differential
POWER STEERING
Tri-Mode Dynamic Power Steering (DPS)


SUSPENSION

FRONT SUSPENSION
Double A-arm 9 in. (22.9 cm) travel
FRONT SHOCKS
Oil
REAR SUSPENSION
Torsional Trailing arm Independent rear suspension (TTI) 9.3 in. (23.6 cm) travel
REAR SHOCKS
Oil


BRAKES

FRONT BRAKES
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
REAR BRAKE
Single 214 mm ventilated disc brake with hydraulic twin-piston calipers


TIRES/WHEELS

FRONT TIRES
Carlisle ACT radial 26 x 8 x 12 in. (66 x 20.3 x 30.5 cm)
REAR TIRES
Carlisle ACT radial 26 x 10 x 12 in. (66 x 25.4 x 30.5 cm)
WHEELS
12 in. cast aluminum


DIMENSIONS/CAPACITIES

L X W X H (IN)
86 x 46 x 49.5 in.
L X W X H (CM)
218.4 x 116.8 x 126 cm
WHEELBASE
51 in. (129.5 cm)
GROUND CLEARANCE
11 in. (27.9 cm)
SEAT HEIGHT
34.5 in. (87.7 cm)
ENGINE / DRY WEIGHT*
767 lb (348 kg)
RACK CAPACITY
Front: 100 lb (45 kg) Rear: 200 lb (90 kg)
STORAGE CAPACITY
Rear: 5.7 gal (21.4 L)
TOWING CAPACITY
1,300 lb (590 kg)
FUEL CAPACITY
5.4 gal (20.5 L)


KEY ITEMS

GAUGE
Multifunction Digital: Speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip & hour meters, diagnostic center, gear position, engine hour meter, 4 x 4 indicator, temperature and engine lights, fuel gauge, clock
WINCH
3,000-lb (1,361 kg) WARN winch with roller fairlead
PROTECTION
Heavy-duty front & rear bumpers, handlebar wind deflectors
INSTRUMENTATION
Lighter type DC outlet in console, standard connector in the back (15-A)
LIGHTING
230-W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light
SEAT
N/A
ANTI-THEFT SYSTEM
Digitally Encoded Security System (D.E.S.S.)


WARRANTY

FACTORY
6 months limited warranty
EXTENDED
B.E.S.T. available from 6 to 30 months


All inventory listed is subject to availability and prior sale. Manufacturer's Suggested Retail Price (MSRP) if shown for a vehicle excludes set-up, freight, taxes, title, licensing or other dealer charges, and is subject to change. Individual prices may vary. Please request a quote for specific pricing.
